0.6μm Aluminum Roughing Endmill H6 3 Flute Roughing End Mill Customized

Brand Name:	AMG
MOQ:	3-10PCS
Payment Terms:	T/T/Credit Card
Supply Ability:	30000-100000pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001

Name:

Aluminum Roughing Endmill

Number Of Flute:

Grain Size:

0.6μm

Coating:

Uncoated

Application:

MDF, Plywood, Solid Wood, Composites

Shank Type:

Straight Shank

Shank Precision:

Manufacturer:

Professional Factory

Packaging Details:

Plastic tube

Supply Ability:

30000-100000pcs per month

Highlight:

0.6μm Aluminum Roughing Endmill

Aluminum Roughing Endmill H6

3 Flute Roughing End Mill Customized

Product Description

0.6μm Aluminum Roughing Endmill H6 3 Flute Roughing End Mill Customized

Product Specifications

Attribute	Value
Name	Aluminum Roughing Endmill
Number of flute	3
Grain size	0.6μm
Coating	Uncoated
Application	MDF, plywood, solid wood, composites
Shank Type	Straight shank
Shank precision	h6
Manufacturer	Professional Factory

Product Description

The AMG 3-Flute Roughing Carbide End Mill is a high-efficiency CNC cutting tool designed for fast material removal in wood, aluminum, and other non-ferrous materials. Its unique 3-flute design combines the chip clearance of a 2-flute end mill with the stability and feed rates of a 4-flute tool, making it ideal for aggressive roughing and semi-finishing.

Key Features

Optimized for Wood & Aluminum - High helix angle (35°-45°) for smooth chip ejection and reduced heat buildup. Razor-sharp cutting edges prevent material tear-out in wood and gumming in aluminum.
3-Flute Design - More cutting edges than a 2-flute for higher feed rates without sacrificing chip clearance. Better stability than a 4-flute for reduced vibration in deep cuts.
Roughing-Specific Geometry - Serrated or variable-pitch flutes break chips into small pieces for easier evacuation. Reduced cutting resistance for longer tool life in abrasive materials.
High-Performance Carbide Substrate - Ultra-fine grain carbide for durability & heat resistance in high-speed machining. Reinforced core prevents deflection in deep-pocket milling.
Specialized Coating (Optional) - Non-stick polished finish for aluminum minimizes built-up edge. Optional TiAlN coating extends tool life in abrasive materials.
High-Speed Machining (HSM) Compatible - Stable at 15,000-25,000 RPM (depending on tool size).

Typical Applications
