| Brand Name: | AMG |
| MOQ: | 3-10PCS |
| Payment Terms: | T/T/Credit Card |
| Supply Ability: | 30000-100000pcs per month |
| Attribute | Value |
|---|---|
| Name | Carbide Thread Milling Cutter |
| Number of flute | 3 |
| Coating | TiAlN / AlCrN |
| Application | Stainless steel, titanium, etc |
| Service | OEM/ODM |
| Taper angle | 1°–10° |
| Cutting Direction | Right Hand |
| Cutting Length | 3mm-30mm |
| Flute Type | Spiral |
| Shank Type | Cylindrical |
This specialized taper thread milling cutter is designed for manufacturing bone screws and orthopedic implants compliant with ASTM F543 (Standard Specification for Metallic Medical Bone Screws). It ensures high precision, biocompatibility, and superior surface finish for medical-grade applications.
| Bone Screw Type | Thread Design | Typical Materials |
|---|---|---|
| Cortical Screws | Fine, sharp threads | 316L Stainless Steel |
| Cancellous Screws | Coarse, deep threads | Ti-6Al-4V, PEEK |
| Locking Screws | Self-tapping, dual-lead | CoCr Alloys |
| Parameter | Value Range | Notes |
|---|---|---|
| Cutting Speed (Vc) | 15-30 m/min | Lower for stainless steel |
| Feed per Tooth (Fz) | 0.02-0.05 mm/tooth | Adjust for thread pitch |
| Coolant | MQL (Minimum Quantity Lubrication) or sterile saline | Avoids contamination |
| Tool Life | 100-300 holes (varies by material) | Monitor wear closely |
We are a professional manufacturer of carbide tools which established in 2017.
All of our carbide tools are produced by imported WALTER grinding machines.
We usually send goods by express like FedEx, UPS, DHL, TNT, EMS, ETC. We also can send products to your shipping agent in China.
