Carbide Thread Milling Cutter

Medical Carbide Thread Milling Cutter 3mm - 30mm Taper Milling Cutter ASTM F543 Bone Cutting

All Category

Carbide Boring Tool

Ms. Niki

niki@carbide-drill.com

+86 17368153006

AMG-TOOLS

Contact Now

Medical Carbide Thread Milling Cutter 3mm - 30mm Taper Milling Cutter ASTM F543 Bone Cutting

Brand Name:	AMG
MOQ:	3-10PCS
Packaging Details:	Plastic tube
Payment Terms:	T/T/Credit Card

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001

Name:

Carbide Thread Milling Cutter

Number Of Flute:

Coating:

TiAlN / AlCrN

Application:

Stainless Steel, Titanium, Etc

Service:

OEM/ODM

Taper Angle:

1°–10°

Cutting Direction:

Right Hand

Cutting Length:

3mm-30mm

Flute Type:

Spiral

Shank Type:

Cylindrical

Supply Ability:

30000-100000pcs per month

Highlight:

Medical Carbide Thread Milling Cutter

Carbide Thread Milling Cutter 3mm

30mm Taper Milling Cutter

Product Description

Medical Carbide Thread Milling Cutter 3mm - 30mm Taper Milling Cutter ASTM F543 Bone Cutting

Product Specifications

Name	Carbide Thread Milling Cutter
Number of flute	3
Coating	TiAlN / AlCrN
Application	Stainless steel, titanium, etc
Service	OEM/ODM
Taper angle	1°–10°
Cutting Direction	Right Hand
Cutting Length	3mm-30mm
Flute Type	Spiral
Shank Type	Cylindrical

Medical Taper Threading Milling Cutter ASTM F543 Bone Cutting

This specialized taper thread milling cutter is designed for manufacturing bone screws and orthopedic implants compliant with ASTM F543 (Standard Specification for Metallic Medical Bone Screws). It ensures high precision, biocompatibility, and superior surface finish for medical-grade applications.

Key Features & Compliance

ASTM F543 Compliance - Designed for cortical and cancellous bone screw threads. Meets dimensional tolerances per ASTM F543 Class 1 (Stainless Steel) & Class 2/3 (Titanium Alloys).

Taper Thread Geometry - Taper Angle: Typically 1°-10° (adjustable per implant design). Thread Profile: Optimized for V-thread or buttress thread (common in bone screws). Pitch Range: 0.5 mm - 2.0 mm (covers most medical screw sizes).

Material & Coating - Tool Material: Ultra-fine carbide substrate (high wear resistance). Coating: AlCrN (Aluminum Chromium Nitride) or DLC (Diamond-Like Carbon) for biocompatibility (FDA-compliant) and extended tool life in titanium (Ti-6Al-4V) and stainless steel (316L).

Precision & Surface Finish - Thread Accuracy: ± 0.005 mm (critical for implant fit). Surface Roughness: Ra ≤ 0.4 µm (minimizes bacterial adhesion).

Applications in Orthopedics

Bone Screw Type	Thread Design	Typical Materials
Cortical Screws	Fine, sharp threads	316L Stainless Steel
Cancellous Screws	Coarse, deep threads	Ti-6Al-4V, PEEK
Locking Screws	Self-tapping, dual-lead	CoCr Alloys

Machining Parameters (Ti-6Al-4V Example)

Parameter	Value Range	Notes
Cutting Speed (Vc)	15-30 m/min	Lower for stainless steel
Feed per Tooth (Fz)	0.02-0.05 mm/tooth	Adjust for thread pitch
Coolant	MQL (Minimum Quantity Lubrication) or sterile saline	Avoids contamination
Tool Life	100-300 holes (varies by material)	Monitor wear closely

Tool Design Variants

Single-Profile Taper Mills - Fixed taper angle (e.g., 2.5° for dental implants). Best for high-volume production (e.g., spinal screws).

Adjustable Taper Mills - CNC-programmable taper (1°-5° via toolpath). Ideal for R&D & custom implants.

Hybrid (Drill + Thread Mill) - Combines drilling & threading in one operation (reduces alignment errors).

Product Images

Special Offers for First-Time Buyers

Frequently Asked Questions

Are you a manufacturer or trading company?

We are a professional manufacturer of carbide tools which established in 2017.

Which CNC grinding machine do you use?

All of our carbide tools are produced by imported WALTER grinding machines.

Which shipping method do you usually use?

We usually send goods by express like FedEx, UPS, DHL, TNT, EMS, ETC. We also can send products to your shipping agent in China.
