3D Carbide Twist Drills 10mm Twist Drill Bits M7 For Iron Cast Iron Inconel

Brand Name:	AMG
Model Number:	DIN-5D
MOQ:	3-10PCS
Packaging Details:	Plastic tube
Payment Terms:	T/T/Credit Card

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001

Product Name:

Carbide Twist Drills

Point Angle:

140° (for Hard Metals)

Material:

Tungsten Carbide

Precision:

M7 Or Customized

Diameter:

4-32mm

Overall Length:

50-400mm

Helix:

30–35° (optimized Chip Flow)

OEM/ODM:

Available

Coolant Method:

Outside Coolant

Application:

Cast Iron, Steel, Inconel, Etc

Supply Ability:

30000-100000pcs per month

Highlight:

3D Carbide Twist Drills

Carbide Twist Drills 10mm

Twist Drill Bits M7

Product Description

3D Carbide Twist Drills 10mm Twist Drill Bits M7 For Iron Cast Iron Inconel

Product Specifications

Attribute	Value
Product name	Carbide Twist Drills
Point angle	140° (for hard metals)
Material	Tungsten carbide
Precision	m7 or customized
Diameter	4-32mm
Overall length	50-400mm
Helix	30–35° (optimized chip flow)
OEM/ODM	Available
Coolant method	Outside coolant
Application	Cast iron, steel, inconel, etc

Product Description

The 3D Solid Carbide 10mm Twist Drill Bit is a high-performance cutting tool engineered for drilling tough materials like iron, cast iron, and Inconel. Featuring an optimized 3D flute geometry, ultra-hard tungsten carbide construction, and advanced coatings, it delivers superior chip evacuation, heat resistance, and extended tool life in demanding industrial applications.

Key Features

3D Flute Design for Enhanced Performance

Aggressive Chip Removal - Unique 3D spiral grooves prevent clogging, even in deep-hole drilling
Reduced Cutting Forces - Smoother penetration in hard-to-machine materials
Minimized Vibration - Improves hole accuracy and surface finish

Solid Tungsten Carbide Construction

Extreme Hardness (90+ HRA) - Ideal for abrasive materials (cast iron, Inconel, hardened steels)
High Heat & Wear Resistance - Maintains sharpness longer than HSS or cobalt drills

Specialized Coating (Optional)

AlTiN (Aluminum Titanium Nitride) - Best for high-temperature alloys (Inconel, Waspaloy)
TiCN (Titanium Carbo-Nitride) - Improves wear resistance in cast iron
Uncoated (Polished) - For non-ferrous metals & general-purpose use

Heavy-Duty Applications

✔ CNC machining, oil & gas, aerospace components
✔ Deep-hole drilling (up to 5× diameter)
✔ High-speed drilling in cast iron & superalloys

Product Images

Promotion Policy

Free sample: If clients can pay shipping fee, could get free samples (under USD20) for testing.

Special offer for new customers: New clients can enjoy USD50 discount coupon for first order, if the total order amount is more than USD500.

Our Advantages

Advanced grinding machines: All of our grinding machines are WALTER and SAACKE brands
Advanced inspection machines: We have ZOLLER, OMEGA, PG1000, etc. For inspecting each carbide tools
Fast feedback: we offer 24 hours online service
Strict quality control system: We strictly adhere to a three-stage inspection process for each tool
