Good price online

products details

Home > Products >
Carbide Deep Hole Drill
>
High Precision Long Flute Drill 8D 12D 15D 20D 25D 30D 40D Carbide Drill Bits For Metal
All Category

Carbide Drill Bit

Through Coolant Drill

Carbide Deep Hole Drill

Carbide Step Drill

Heavy Duty Drill Bit

Tungsten Carbide Tools

Carbide End Mill

Custom End Mill

Carbide Thread Milling Cutter

Solid Carbide Tap

PCD Milling Cutter

Carbide End Mill Cutter

Solid Carbide Reamer

Carbide Boring Tool
Contact Us
Ms. Niki
niki@carbide-drill.com
+86 17368153006
wechat AMG-TOOLS
Contact Now
name
  • name
  • name
  • name
  • name
  • name

High Precision Long Flute Drill 8D 12D 15D 20D 25D 30D 40D Carbide Drill Bits For Metal

Brand Name: AMG
MOQ: 3-10PCS
Packaging Details: Plastic tube
Payment Terms: T/T/Credit Card
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
ISO9001
Product Name:
Long Flute Drill
Length Options:
8xD 12xD 15xD 20xD 25xD 30xD 40xD
Application:
Aluminium, Cast Iron, Steel, Inconel 718, Titanium, Etc
Coating:
Customized
Shank Type:
Round
Point Angle:
135 Degrees
Material:
Carbide
Precision:
High Precision
Usage:
Metal Drilling
Flute Type:
Spiral
Supply Ability:
30000-100000pcs per month
Highlight:

High Precision Long Flute Drill

,

Long Flute Drill 8D

,

40D Carbide Drill Bits For Metal

Product Description
High Precision Long Flute Drill 8D 12D 15D 20D 25D 30D 40D Carbide Drill Bits For Metal
Product Specifications
Attribute Value
Product name Long Flute Drill
Length Options 8xD 12xD 15xD 20xD 25xD 30xD 40xD
Application Aluminium, cast iron, steel, Inconel 718, titanium, etc
Coating Customized
Shank Type Round
Point Angle 135 degrees
Material Carbide
Precision High precision
Usage Metal drilling
Flute Type Spiral
Product Description

AMG's premium extra-long carbide drills redefine deep hole machining with exceptional stability and precision across extended flute lengths (8D to 40D). Designed for challenging applications where standard drills fail, these tools deliver uncompromising accuracy and tool life in deep cavity machining.

High Precision Long Flute Drill 8D 12D 15D 20D 25D 30D 40D Carbide Drill Bits For Metal 0
8D Carbide Drill Specifications
Flute dia (D) Shank dia (d) OAL(L) Groove length (L1) Shank length(LS)
3 6 72 34 36
3.1 6 72 34 36
3.2 6 72 34 36
3.3 6 72 34 36
3.4 6 72 34 36
3.5 6 72 34 36
3.6 6 72 34 36
3.7 6 72 34 36
3.8 6 81 43 36
3.9 6 81 43 36
4 6 81 43 36
12D Carbide Drill Specifications
Flute dia (D) Shank dia (d) OAL(L) Groove length (L1) Shank length(LS)
3 6 90 50 36
3.1 6 90 50 36
3.2 6 90 50 36
3.3 6 90 50 36
3.4 6 90 50 36
3.5 6 90 50 36
3.6 6 90 50 36
3.7 6 90 50 36
3.8 6 102 64 36
3.9 6 102 64 36
4 6 102 64 36
Tags:

Deep Hole Drill Bits

Long Flute Drill

Cemented Carbide Drill Bits
