Carbide End Mill

2 Flutes Carbide End Mill Cutter 30 Degree 45 Degree TiAlN Coated End Mills

All Category

Carbide Boring Tool

Ms. Niki

niki@carbide-drill.com

+86 17368153006

AMG-TOOLS

Contact Now

2 Flutes Carbide End Mill Cutter 30 Degree 45 Degree TiAlN Coated End Mills

Brand Name:	AMG
MOQ:	3-10PCS
Packaging Details:	Plastic tube
Payment Terms:	T/T/Credit Card

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001

Name:

Carbide End Mill Cutter

Grain Size:

0.6μm

Coating:

TiAlN Dark Purple Color

Flute Type:

Spiral Flute

Application:

Cast Iron, Steel, Stainless Steel, Inconel 718, Etc

Shank Type:

Straight Shank

Size:

Various Sizes Available

Helix Angle:

30° Or 45 °

Supply Ability:

30000-100000pcs per month

Highlight:

2 Flutes Carbide End Mill Cutter

30 Degree TiAlN Coated End Mills

45 Degree TiAlN Coated End Mills

Product Description

2 Flutes Carbide End Mill Cutter 30° & 45° TiAlN Coated End Mills

Attribute	Value
Name	Carbide End Mill Cutter
Grain size	0.6μm
Coating	TiAlN dark purple color
Flute type	Spiral flute
Application	Cast iron, steel, stainless steel, inconel 718, etc
Shank Type	Straight shank
Size	Various sizes available
Helix angle	30° or 45°

Premium 2-Flute Carbide End Mills with TiAlN Coating

AMG's 2-flute carbide end mills with advanced TiAlN coating deliver exceptional performance in steel machining operations. Designed for optimal material removal and finish quality, these tools combine rigidity, heat resistance, and long tool life for your most challenging milling applications.

Key Features

Ultra-Fine Grain Carbide Substrate
- High transverse rupture strength (≥4,200 N/mm²)
- Excellent wear resistance for prolonged tool life
- Optimized for steels (HRC 20-50)
Advanced TiAlN Coating
- Extreme heat resistance (up to 900°C)
- Low friction coefficient for smooth cutting
- 3-5μm coating thickness for durability
Optimized 2-Flute Geometry
- 30° helix angle for balanced chip evacuation
- Sharp cutting edges for reduced cutting forces
- Center-cutting design for plunge milling
