Carbide End Mill

0.4μm 2 Flute End Mills Solid Carbide Taper End Mill Customized With TiAlN Coating

All Category

Carbide Boring Tool

Ms. Niki

niki@carbide-drill.com

+86 17368153006

AMG-TOOLS

Contact Now

0.4μm 2 Flute End Mills Solid Carbide Taper End Mill Customized With TiAlN Coating

Brand Name:	AMG
MOQ:	3-10PCS
Packaging Details:	Plastic tube
Payment Terms:	T/T/Credit Card

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001

Name:

2 Flute End Mills

Grain Size:

0.4μm

Coating:

TiAlN Dark Purple Color

Flute Type:

Taper Flute Type End Mill

Application:

Cast Iron, Steel, Stainless Steel, Inconel 718, Etc

Shank Type:

Straight Shank

Size:

Various Sizes Available

Taper Angle:

1-20°/customized

Supply Ability:

30000-100000pcs per month

Highlight:

0.4μm 2 Flute End Mills

Solid Carbide Taper End Mill

Carbide Taper End Mill Customized

Product Description

0.4μm 2 Flute End Mills Solid Carbide Taper End Mill Customized With TiAlN Coating

Attribute	Value
Name	2 Flute End Mills
Grain size	0.4μm
Coating	TiAlN dark purple color
Flute type	Taper flute type end mill
Application	Cast iron, steel, stainless steel, inconel 718, etc
Shank Type	Straight shank
Size	Various sizes available
Taper angle	1-20°/customized

2 Flutes Solid Carbide Taper End Mill With TiAlN Coating 17-4PH Steel

AMG's 2-flute solid carbide taper end mills with advanced TiAlN coating deliver exceptional performance in mold/die and aerospace applications. These tools combine rigidity, heat resistance, and superior finish quality for machining complex tapered surfaces and deep cavities.

Key Features

Premium Micro-Grain Carbide - 0.4μm grain structure for optimal edge retention with high transverse rupture strength (4,500 N/mm²), specialized for hardened steels (HRC 20-55)
Advanced TiAlN Coating - Withstands 900°C cutting temperatures, reduces built-up edge in sticky materials, 3-5μm thickness for extended tool life
Optimized Taper Geometry - 1°-5° taper angles (standard/custom), 30° helix angle for smooth chip flow, sharp cutting edges for reduced deflection

Performance Advantages

For CNC Programmers: Maintains dimensional accuracy in deep cavities, reduces hand polishing time by 50%, enables high-speed machining strategies.

For Mold/Die Applications: Perfect for draft angle machining, excellent finish in hardened steels (Ra 0.3μm), eliminates multiple tool changes.

Typical Applications

Injection mold core/cavity machining
Aerospace turbine blade roots
Medical implant tapered surfaces
Die-casting mold maintenance

AMG Quality Assurance

100% laser-inspected taper accuracy
Dynamic balanced for >20,000 RPM
Serialized traceability

Custom Options Available

Special taper angles
Variable helix designs
Neck relief for deep cavities

Product Images
