0.8μm Single Flute Router Bits Uncoated CNC Router Drill Bits H6 For MDF Plywood

Brand Name: AMG
MOQ: 3-10PCS
Packaging Details: Plastic tube
Payment Terms: T/T/Credit Card
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
ISO9001
Name:
Single Flute Router Bits
Number Of Flute:
1
Grain Size:
0.6μm Or 0.8μm
Coating:
Uncoated
Application:
Acrylic, PVC, MDF, And Softwoods
Shank Precision:
H6
Tolerance:
0/-0.02mm
Service:
OEM/ODM
Supply Ability:
30000-100000pcs per month
Highlight:

0.8μm Single Flute Router Bits

,

Uncoated CNC Router Drill Bits

,

CNC Router Drill Bits H6

Product Description
0.8μm Single Flute Router Bits Uncoated CNC Router Drill Bits H6 For MDF Plywood
Product Specifications
Attribute Value
Name Single Flute Router Bits
Number of flute 1
Grain size 0.6μm or 0.8μm
Coating Uncoated
Application Acrylic, PVC, MDF, and softwoods
Shank precision h6
Tolerance 0/-0.02mm
Service OEM/ODM
Product Overview

Single-flute CNC router bit is a specialized cutting tool designed with only one cutting edge (flute) for optimized performance in specific materials, particularly plastics, wood composites (MDF, plywood), and non-ferrous metals.

Key Features
  • Single Cutting Edge: Reduces friction and heat buildup vs. multi-flute designs
  • Large Chip Channel: 50-70% more chip space than 2-flute bits
  • Shear Geometry: Typically 30-45° helix angle for clean cuts
  • Material: Solid carbide (common) or carbide-tipped
Performance Advantages
Benefit Technical Rationale
Higher Feed Rates Less tool engagement → faster material removal
Better Chip Clearance Prevents resin/clogging in MDF/plywood
Reduced Vibration Single-edge cutting minimizes harmonic chatter
Longer Tool Life Lower heat generation in abrasive materials
Recommended Applications
  • MDF/Plywood: Prevents burning and edge fraying
  • Plastics/Acrylics: Delivers polished edges
  • Aluminum: Effective for thin-stock machining
  • Foam/Composite Boards: Clean cuts without tearing
Product Images
0.8μm Single Flute Router Bits Uncoated CNC Router Drill Bits H6 For MDF Plywood 0
Manufacturing Facility
0.8μm Single Flute Router Bits Uncoated CNC Router Drill Bits H6 For MDF Plywood 1 0.8μm Single Flute Router Bits Uncoated CNC Router Drill Bits H6 For MDF Plywood 2
Special Offers for New Customers
Free Test Samples

Get free samples (total value ≤ $20 USD) when you cover the international shipping cost. Perfect for evaluating our product quality and performance risk-free.

$50 USD Discount on First Order

New customers can enjoy a $50 discount on the first order of $500 or more. A great way to start our partnership with extra value!

Related Products
0.8μm Single Flute Router Bits Uncoated CNC Router Drill Bits H6 For MDF Plywood 3
Frequently Asked Questions
Are you a manufacturer or trading company?

We are a professional manufacturer of carbide tools which established in 2017.

Which CNC grinding machine do you use?

All of our carbide tools are produced by imported WALTER grinding machines.

Which shipping method do you usually use?

We usually send goods by express like FedEx, UPS, DHL, TNT, EMS, etc. We also can send products to your shipping agent in China.
